SPGT Carbide Inserts for Indexable U-Drills and Aluminum Drilling
SPGT carbide inserts feature a sharp positive cutting geometry for compatible indexable U-drills and non-ferrous holemaking. Polished or uncoated edge options help reduce material adhesion when drilling aluminum, while multiple sizes support distributors supplying replacement inserts for different drill diameters.
جودة متسقة
Consistent geometry across repeat orders.
الطلبات المرنة
Small batches and mixed sizes available.
OEM Support
Custom marking, labels and packaging.
قياسي ومخصص
Standard sizes and custom configurations.
نظرة عامة على المنتج
إن SPGT carbide insert series is designed for indexable U-drills used in high-efficiency aluminum and non-ferrous metal drilling. Its sharp positive cutting geometry helps reduce cutting resistance, cutting heat and material adhesion while supporting stable chip formation and consistent hole quality.
Available models include SPGT050204, SPGT060204, SPGT07T308, SPGT090408, SPGT110408 and SPGT140512.
The broad size range helps customers match different U-drill bodies and build a more complete indexable drilling product line. More insert options can be found in our indexable carbide insert range.
Quick Procurement Summary
| Insert Series | SPGT05 / SPGT06 / SPGT07 / SPGT09 / SPGT11 / SPGT14 |
| التطبيق الأساسي | Indexable U-drilling and CNC holemaking |
| Workpiece Materials | Aluminum, aluminum alloys and selected non-ferrous metals |
| Standard Pack | 10 pieces per box |
| Order Options | Standard models and mixed-model orders by confirmation |
| Packaging Support | Neutral or private-label packaging by confirmation |
Features for Aluminum Drilling
Product Video
SPGT050204 and SPGT060204 U-drill insert reference video. Actual drilling performance depends on the U-drill body, workpiece alloy, machine rigidity, coolant and cutting parameters.
Available SPGT Models
Please confirm the complete insert code and U-drill holder model before ordering. Inserts with similar appearances may have different dimensions or compatible pockets.
| الطراز | Insert Family | Typical Application | التوريد |
|---|---|---|---|
| SPGT050204 | SPGT05 | Small-diameter U-drilling | Confirm before order |
| SPGT060204 | SPGT06 | Small-diameter U-drilling | Confirm before order |
| SPGT07T308 | SPGT07 | Medium-size U-drilling | Confirm before order |
| SPGT090408 | SPGT09 | Medium-size U-drilling | Confirm before order |
| SPGT110408 | SPGT11 | Larger compatible U-drills | Confirm before order |
| SPGT140512 | SPGT14 | Larger compatible U-drills | Confirm before order |
Information Required for Model Matching
Provide the SPGT size, grade and chipbreaker designation.
Send the model marked on the drill body or provide a clear photograph.
Specify the aluminum grade or other non-ferrous material.
Provide the quantity, mixed-model plan and packaging preference.
For additional guidance on insert designations and workpiece-material selection, read our carbide insert types guide.
Why Customers Choose This Series
Complete SPGT coverage: Multiple standard sizes help customers build a broader U-drill insert range.
Mixed-model orders: Selected SPGT sizes may be combined according to the confirmed order plan.
Stable repeat supply: Insert codes, grades and packaging details can be recorded for repeat orders.
Customer packaging: Neutral boxes, barcode labels, customer SKU labels and private-label packaging are available.
SPGT Insert Specifications
The overview lists six SPGT carbide insert models for compatible indexable U-drills. Select by the complete drill-body and insert codes, then confirm the insert pocket, center or peripheral position, carbide grade and aluminum-specific cutting geometry. A model number alone does not identify the finished hole diameter.
| Listed model | السلسلة | Pocket / position check |
|---|---|---|
| SPGT050204 | SPGT05 | Confirm the SPGT05 drill-body pocket and insert position. |
| SPGT060204 | SPGT06 | Confirm the SPGT06 drill-body pocket and insert position. |
| SPGT07T308 | SPGT07 | Confirm the SPGT07 drill-body pocket and insert position. |
| SPGT090408 | SPGT09 | Confirm the SPGT09 drill-body pocket and insert position. |
| SPGT110408 | SPGT11 | Confirm the SPGT11 drill-body pocket and insert position. |
| SPGT140512 | SPGT14 | Confirm the SPGT14 drill-body pocket and insert position. |
Model list transcribed from the current product overview. The page does not include verified insert dimensions, mounting-hole details or a drill-diameter cross-reference for these six HY items.
Configuration & Holder Matching
| المواصفات | What to confirm |
|---|---|
| Insert type | Positive-clearance square SPGT carbide insert; verify the complete model and chipbreaker suffix. |
| قطعة العمل | Aluminum and selected non-ferrous alloys; identify the exact alloy and silicon content. |
| Grade / surface | Confirm carbide grade and whether the ordered edge is polished, uncoated or coated. These options are not interchangeable by appearance. |
| Drill-body match | Check pocket dimensions, insert seat, screw and center/peripheral positions against the drill manufacturer's parts list. |
| Hole configuration | Hole diameter, drilling depth, through/blind exit, machine type and coolant delivery follow the complete U-drill assembly. |
| Pack / OEM | Overview states 10 pieces per box; confirm each item, mixed-model quantity and requested label or private-label pack. |
Cutting Data & Selection Notes
Set cutting speed and feed per revolution from the complete U-drill body, insert grade and aluminum alloy. Check spindle power, drill overhang, coolant pressure/flow and chip removal before a production run. With center and peripheral pockets, follow the drill body's specified insert combination and cutting limits.
The original page provides no verified speed/feed chart for these six configurations. Do not transfer another manufacturer's cutting values or infer a hole diameter from the SPGT insert code.
For a matching insert drawing and starting cutting data, send the drill-body code, insert code, aluminum grade and required quantity. See the broader SPMG/SPGT/SPMT U-drill insert range.
◆Carbide Insert Customization & OEM
Specify the insert around the machining operation, workpiece and holder. We can review standard replacements, application-specific geometry and private-label requirements using your insert designation, drawing or sample. Available grades, coatings, dimensions and order quantities are confirmed for each requested series.
Geometry & Chip Control
Review chipbreaker, rake, cutting-edge preparation, nose radius and corner design for the operation and workpiece. Confirm holder compatibility before approving a modified geometry.
Substrate & Coating
Select an available carbide grade and coating for the workpiece material, cutting conditions and desired balance of wear resistance and edge toughness.
Dimensions & OEM
Review insert size, thickness, locating and clamping features, tolerances, laser marking and private-label packaging against the approved specification.
◆Customization Options
Use the fields below when sending an inquiry. The exact options depend on the insert family and are confirmed in the quotation or approved drawing.
| المواصفات | Details to Confirm |
|---|---|
| Insert Type | Turning, milling, threading, grooving or drilling insert; send the designation or drawing. |
| Size & Fit | Shape, size, thickness, inscribed circle or edge length, hole or clamping form, and holder model. |
| هندسة القطع | Chipbreaker, nose or corner radius, edge preparation, cutting direction and application-specific profile. |
| Grade & Coating | Workpiece group and grade, carbide substrate, coating system and wet or dry cutting conditions. |
| Tolerance & Inspection | Critical dimensions, profile requirements, inspection method and any required report. |
| OEM Presentation | Insert or box marking, label content, packaging format and quantity per pack. |
◆How to Request a Custom Insert
Send your insert requirements through our contact form or review our OEM and private-label service.
◆Carbide Insert Quality Control
Insert quality depends on the approved grade, geometry, coating and dimensional specification. We review the requirements at order confirmation and align the inspection scope with the insert series and any customer drawing. Share critical dimensions or documentation needs before production so they can be included in the agreed inspection plan.
01 · Incoming Material
Confirm the specified carbide grade or material documentation against the order requirements.
02 · In-Process Checks
Review dimensions and cutting-edge features during production against the approved specification.
03 · Final Inspection
Check the agreed dimensions, appearance, edge condition, coating identification and marking as applicable.
04 · Packing Review
Verify the item code, quantity, labels and protective packing against the approved order.
◆Inspection & Documentation
Inspection points and acceptance criteria should be agreed for the ordered series. For custom inserts, the approved drawing takes priority over a generic catalogue description.
| Check Area | What to Confirm |
|---|---|
| Dimensions & Fit | Insert size, thickness, corner radius, clamping features and any drawing tolerances. |
| هندسة القطع | Chipbreaker, edge preparation, usable corners and profile where applicable. |
| Grade & Coating | Approved grade and coating designation; any requested verification method. |
| Appearance & Packing | Visible edge damage, marking, item code, count and packing format. |
| Requested Records | Inspection report, material or coating documentation, sample approval or batch identification when agreed. |
◆Order & Delivery
Share a line-by-line list of insert codes and quantities for a mixed-size quotation. Stock status, minimum quantity, sample requirements and production lead time are confirmed for each grade, coating and configuration.
Send your item list and quality requirements through our contact form for specification, availability and delivery confirmation.
Product FAQs
Which SPGT models are listed for this range?
The current product description lists SPGT050204, SPGT060204, SPGT07T308, SPGT090408, SPGT110408 and SPGT140512. Confirm the complete code, grade, chipbreaker and stock status for each item.
Can I select the insert from the hole diameter alone?
No. The drill body's model and parts list determine the insert size, pocket and center or peripheral position. The SPGT code does not by itself state the finished drill diameter.
Are all SPGT inserts interchangeable with other U-drill brands?
Do not assume interchangeability from the SPGT shape and size code. Compare the complete insert geometry, thickness, mounting hole, edge preparation, pocket and retaining screw with the drill manufacturer's approved parts list.
What edge is suitable for aluminum drilling?
A sharp positive edge and suitable smooth rake face can help reduce adhesion and cutting resistance. Confirm whether the selected HY model has a polished, uncoated or coated surface and whether its grade suits the exact aluminum alloy, especially high-silicon grades.
Can the same insert be used in the center and outer positions?
That depends on the U-drill body. Some indexable drills specify different center and peripheral insert geometries or grades. Check both positions and follow the approved insert combination for the complete holder code.
What speeds and feeds should I use?
Use starting values supplied for the specific drill body, insert grade, diameter and aluminum alloy. Adjust for drilling depth, machine rigidity, coolant delivery and chip behavior. The overview does not provide a verified cutting-data chart for every SPGT model.
Ordering & OEM FAQs
What should I send for an exact replacement quote?
Send the U-drill body code and clear photos of the insert or box label, plus the full SPGT code, center/peripheral position, workpiece alloy, required quantity and current cutting conditions.
Can I combine several SPGT sizes in one order?
Yes, send a line-by-line list of full insert codes, grades and quantities. Mixed-model supply and minimum order quantities are confirmed against each item and the order plan.
How are these inserts packed?
The current overview states 10 pieces per box. Confirm the actual pack quantity for each code when ordering; neutral boxes, barcodes, customer SKU labels and private-label packs can be reviewed with the quotation.
Can I request a sample before a larger order?
Provide the complete drill and insert codes, aluminum alloy, hole diameter/depth and evaluation conditions. Sample availability and trial quantity are confirmed by configuration.
Guides & Technical References
Read the Carbide Insert Types Guide for insert designations and the SPMG/SPGT/SPMT U-drill insert range for related families.
For drawings, holder fit or a quote, send the complete U-drill and insert codes.
Need Sizes, Pricing or Custom Options?
Send us the required tool type, sizes, quantities, workpiece material and any OEM or custom requirements. We will confirm suitable specifications, availability, lead time and quotation details.
Drawings, size lists and reference photos are welcome.
